In aqua Pump linea centrifuga

Model:CNG90/CNG100/CNG130

Ut unus de fabrica professionali, RISEFULL® tibi praebere velim qualitatem altam In linea aquae Pump centrifugae. Et offeremus tibi optimam post venditionem servitii et opportunam traditionem.

Mitte Inquisitionem

depictio producti

Ex materia summo qualitas facta, Aquae Centrifugae In-lineae Pump valde durabilis et diuturna est, prospiciendo ut magnas effectus per multos annos venire possitis. Magnitudo eius compacta etiam facilem facit ad institutionem et operandum, ut uacare statim possis! Etiam sonum habet low campester et vibratio, ut aequaliter, quiete currit, et perturbationes in opere ambitus non facit.

Prooemium est CNG Series . Aquae centrifugae in linea sentinae quae in systemate circulatione refrigerationis et aquae circulationes calidae adhibetur . Spes est auxilium tu melius intellege Sentinae aquae Indutrialis Riseful . Exspectate clientes novos et veteres pergere ad cooperandum nobis ut melius futurum simul crearent

Product Specification:

Product nomen:	In linea Centrifugae Pump
Potestas	0.27HP/0.4HP/0.5HP
Max flow	60L/min 70L/min 90L/min
Max Caput	9M 13M 20M
Inlet / exitus	1"X1"
Sentinam Corpus	Ferrum cum Electore coating
Bracket	Ferrum mittite
Bracket Plate	Ferrum cum Electore coating
Shaft	S.S Shaft
Impeller	PPO Impeller / Brass Impeller
Motor	Filum aeris
Color	Pulvis Color Coating
MOQ:	100pcs
Sample tempus:	Intra VII dies
Tempus productionis:	35-40 diebus post ordinem confirmationis
Testimonium	CE

Product Details

In line centrifugal Water Pump

Opus Condition

Tersus liquor sine suspendendi solidorum, non infestantibus

Continua Service: S1

Maximum Pressura: X Bar

Liquid Temperature:0℃~90℃

Ambiens Temperature:<40℃

Insulation: B

Praesidium: IP44

Data

In line centrifugal Water Pump

Exemplar		Potestas		Q	m³/h	0	0.6	1.2	1.8	2.4	3.0	3.6	4.2	4.8	5.4
Unius phase	Tres tempus	kW	HP	Q	L/min	0	10	20	30	40	50	60	70	80	90
CNG90	CNG90T	0.2	0.27	H	M	9	8.5	8	*7.5	*7	*6	4
CNG100	CNG100T	0.3	0.4			13	12	11.5	*11	*10	*9	*7.5	6.5
CNG130	CNG130T	0.37	0.5			20	19.5	19	18	17.5	16.5	*15.5	*14.5	*13	11

*High Effectus Eta Pump

Exploded View of Main Component

In line centrifugal Water Pump

Indicem Main Component Signare figurationem 〇 Configurationis libitum
NO.	Component	Specification/Construction Characteres
1	ANTLIA CORPORIS	Ferrum HT200, Electro-faciens Bum (Sal Spray obsistens tium 300+ Horae)
2	IMPELLER	●Brass（H58%+）〇 PPO（ Caloris caloris resistens pro 150℃）〇 Steel（SUS304 Stamping & Welding
3	Mechanica Sigillum	〇301 Type（Karbate impervious Graphite + Ceramic） CN Type（Karbate impervious Graphite + Ceramic, Praecipua Constructione Stare Pro Committitur-subsisto Frequenter） ●14DIN Type（Furan Impregnation Graphite+SIC， usus vitae 25,000+ Horae）
4	Bracket Plate	Ferrum HT200, Electro-faciens Bum (sal Spray obsistens tium 300+ Horae) 〇PPO（ Altus Temperature Repugnans Pro 150℃）
5	Bracket	Ferrum HT200
6	Globus Bearings	〇 Standard Type ● C&U 〇 TPI(Taiwan)
7	Motor Shaft	Welding Shaft: Diver CCCIV (Pump Latus) + Carbon Steel (Motor Latus)
8	Terminatio Box	Plastic ABS
9	Terminatio Tabula	Flamma retardans PBT
10	Capacitor	●CBB60 Testa plastica Capacitor 〇 CBB65 Explosio-probatio Capacitor 〇 450VL@220-240V Motor 〇 300VL@110-127VMotor
11	Motor habitationi	aluminium ADC12
12	Fan	●Plastic PP 〇 Nylon PA6
13	Fan Cover	Plastic PP
14	Plug Funiculus	● 3 Core Testimentum Cable 〇 Cables Plug
15	Motor	〇 Vexillum Filum Cupri ● Motorem Oeconomicum Motor 3-Phase Motor 〇 Motoris 60 HZ Motor
