Una ex clavis linearum CPM Style aquae Pump est eius constructio durabilis. Ex GENERE materiae factae, haec sentina aedificatur ad duritias usus quotidiani sustinendi. Utrum aquam e puteo, cisterna vel flumine flare vis, haec sentina cito et efficaciter officium obtinebit.
Prooemium est CN Series . Sentinae aquae centrifugae quae in refrigeratione circulatione rationum adhibetur . Spes adiuvandi melius intelleget Sentinam aquae Indutrialis Riseful . Exspectate clientes novos et veteres pergere ad cooperandum nobis ut melius futurum simul crearent
|
Product nomen: |
Centrifugae Pump |
|
Potestas |
0.5HP/0.65HP/0.75HP/1HP/1.3HP |
|
Max flow |
90L/min 100L/min 110L/min 120L/min 130L/min |
|
Max Caput |
20M 25M 28M 30M 34M |
|
Inlet / exitus |
1"X1" |
|
Sentinam Corpus |
Ferrum cum Electore coating |
|
Bracket |
Ferrum mittite |
|
Bracket Plate |
Ferrum cum Electore coating |
|
Shaft |
S.S Shaft |
|
Impeller |
PPO Impeller / Brass Impeller |
|
Motor |
Filum aeris |
|
Color |
Pulvis Color Coating |
|
MOQ: |
100pcs |
|
Sample tempus: |
Intra VII dies |
|
Tempus productionis: |
35-40 diebus post ordinem confirmationis |
|
Testimonium |
CE |
Tersus liquor sine suspendendi solidorum, non infestantibus
Continua Service: S1
Maximum Pressura: X Bar
Liquid Temperature:0℃~90℃
Ambiens Temperature:<40℃
Insulation: B
Praesidium: IP44
|
Exemplar |
Potestas |
Q |
m³/h |
0 |
0.6 |
1.2 |
1.8 |
2.4 |
3.0 |
3.6 |
4.2 |
4.8 |
5.4 |
6.0 |
6.6 |
||
|
Unius phase |
Tres tempus |
kW |
HP |
L/min |
0 |
10 |
20 |
30 |
40 |
50 |
60 |
70 |
80 |
90 |
100 |
110 |
|
|
CN130 |
CN130T |
0.37 |
0.5 |
H |
M |
20 |
19.5 |
19 |
18 |
17.5 |
16.5 |
*15.5 |
*14.5 |
*13 |
11 |
||
|
CN140 |
CN140T |
0.5 |
0.65 |
25 |
24.5 |
23.5 |
22.5 |
21.5 |
*20.5 |
*19 |
*17.5 |
16 |
14 |
10.5 |
|||
|
Cn146 |
CN146T |
0.55 |
0.75 |
28 |
27.5 |
26.5 |
26 |
25 |
24.5 |
24 |
23 |
*22 |
*21 |
*19 |
6 |
||
|
Cn150 |
CN150T |
0.75 |
1 |
30 |
29 |
28.5 |
28 |
27.5 |
27 |
26.5 |
* 25.5 |
* 24.5 |
*23.5 |
*22 |
20.5 |
||
|
CN155 |
CN155T |
1 |
1.3 |
34 |
33 |
32 |
31 |
30 |
29 |
28 |
*27 |
*26 |
*23.5 |
*21 |
18.5 |
||
*High Effectus Eta Pump
|
NO. |
S/N |
NO. |
S/N |
NO. |
S/N |
|
01 |
Screw |
11 |
Bracket Cover |
21 |
Screw |
|
02 |
Exhaurire Plug |
12 |
Screw |
22 |
Terminatio Sleeve |
|
03 |
O inauris |
13 |
Bracket |
23 |
Clavis |
|
04 |
Exhaurire Plug |
14 |
Ferens |
24 |
Solum Support |
|
05 |
Sentinam Corpus |
15 |
Rotor |
25 |
Cable Fairlead |
|
06 |
Nucis |
16 |
Stator |
26 |
Ver elementum |
|
07 |
elementum |
17 |
Screw |
27 |
Back Cover |
|
08 |
Impeller |
18 |
Tterminal Box |
28 |
Fan |
|
09 |
Mechanica Sigillum |
19 |
Capacitor |
29 |
Fan Cover |
|
10 |
O inauris |
20 |
Terminatio Tabula |
30 |
Screw |
|
Exemplar |
DN1 |
DN2 |
Main Intallation Dimension (mm) |
||||||||||
|
a |
f |
h |
h1 |
i |
l |
m |
n |
n1 |
w |
s |
|||
|
CN130 |
G1 |
G1 |
43 |
265 |
189 |
88 |
35 |
211 |
101 |
167 |
130 |
60 |
17 |
|
CN140 |
G1 |
G1 |
48 |
295 |
213 |
101 |
39 |
239 |
111 |
187 |
150 |
61 |
17 |
|
Cn146 |
G1 |
G1 |
48 |
295 |
213 |
101 |
39 |
239 |
111 |
187 |
150 |
61 |
17 |
|
Cn150 |
G1 |
G1 |
48 |
295 |
213 |
101 |
39 |
239 |
111 |
187 |
150 |
61 |
17 |
|
CN155 |
G1 |
G1 |
48 |
295 |
213 |
101 |
39 |
239 |
111 |
187 |
150 |
61 |
17 |
|
Item |
1~220V/50Hz |
3~ 380V/50Hz |
|
CN130 |
3A |
2A |
|
CN140 |
5A |
1.8A |
|
Cn146 |
5.4A |
1.9A |
|
Cn150 |
5.7A |
2A |
|
CN155 |
7A |
2.4A |
|
Exemplar |
N.W. |
PCS/CTN |
G.W/CTN |
MEAS CM) |
|
CN130 |
8.9 |
1 |
9.30 |
30.5X18X26 |
|
CN140 |
11.75 |
1 |
12.25 |
32.5X22X29.5 |
|
Cn146 |
13.35 |
1 |
14.05 |
32.5X22X29.5 |
|
Cn150 |
13.70 |
1 |
14.30 |
32.5X22X29.5 |
|
CN155 |
15.30 |
1 |
16.05 |
32.5X22X29.5 |
