In suo nucleo, Magnum Periphericum Pump ordinatur cum motore valido et impulsore technologiae provectae ut summus effectus aquae potentia flare studeat.
Una ex eminentibus lineamentis Premium Periphericis Pump eximia eius durabilitas est. Factus ex praecipuis materiis et machinatis ad condiciones durissimas sustinendas, haec sentina ad durandum aedificata est. Cum suo facile-adhibitione et consilio intuitive panel, Magnum Periphericum Pump etiam incredibiliter facile ad operandum est.
Prooemium PN Series haec est . Est premium Aquae Periphericae Pump quod est maxime popularis aquae superficies soleatus . Spera adiuvare melius intelleges Sentinae aquae industriae Riseful . Exspectate clientes novos et veteres pergere ad cooperandum nobis ut melius futurum simul crearent
|
Product nomen: |
Aqua Pump periphericis |
|
Potestas |
0.45HP/0.5HP/0.75/HP/1HP |
|
Max flow |
36L/min 42L/min 55L/min 68L/min |
|
Max Caput |
32M 36M 42M 48M |
|
Inlet / exitus |
1"X1" |
|
Sentinam Corpus |
Ferrum cum Electore coating |
|
Bracket |
Aluminium Bracket cum PPO inserta |
|
Shaft |
S.S Shaft |
|
Impeller |
aes Impeller |
|
Motor |
Filum aeris vel Aluminium |
|
Color |
Pulvis Color Coating |
|
MOQ: |
100pcs |
|
Sample tempus: |
Intra VII dies |
|
Tempus productionis: |
35-40 diebus post ordinem confirmationis |
|
Testimonium |
CE |
Tersus liquor sine suspendendi solidorum, non infestantibus
Maximum Pressura: X Bar
Liquid Temperature:3℃~90℃
Ambiens Temperature:<40℃
Insulation: B
Praesidium: IP44
● Diameter Solidus:≤2mm
|
Exemplar |
Potestas |
Q |
m³/h |
0 |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
3.9 |
||
|
Unius phase |
TRIBUS |
kW |
HP |
L/min |
0 |
5 |
10 |
15 |
20 |
25 |
30 |
35 |
40 |
45 |
50 |
55 |
60 |
65 |
|
|
PS59 |
PS59T |
0.33 |
0.45 |
H |
M |
32 |
28 |
24.5 |
*20.5 |
*16 |
*12 |
*18.5 |
4 |
||||||
|
PS60 |
PS60T |
0.37 |
0.5 |
36 |
32 |
28 |
24 |
*19.5 |
*15 |
*11 |
7 |
3 |
|||||||
|
PS65 |
PS65T |
0.55 |
0.75 |
42 |
38 |
34 |
30 |
26 |
*22 |
*18 |
*14 |
*10 |
6.5 |
3 |
|||||
|
PS70 |
PS70T |
0.75 |
1 |
48 |
44 |
40 |
36 |
32 |
28.5 |
*25 |
*21.5 |
*18 |
*15 |
*12 |
9 |
6 |
|||
*High Effectus Eta Pump
|
Indicem Main Component Signare figurationem 〇 Configurationis libitum |
||
|
NO. |
Component |
Specification/Construction Characteres |
|
1 |
ANTLIA CORPORIS |
Ferrum HT200, Electro-faciens Bum (Sal Spray obsistens tium 300+ Horae) |
|
2 |
IMPELLER |
●Brass（H58%+） 〇 PPO（ Caloris caloris resistens pro 150℃） 〇 Steel（SUS304 Stamping & Welding |
|
3 |
Mechanica Sigillum |
●301 Type（Karbate impervious Graphite + Ceramic） |
|
4 |
Bracket Plate |
●PPO（ Altis Temperature Repugnans Pro 150℃）〇 Praecisione Iactandi SUS304 〇 Aes(H57%+) |
|
5 |
Bracket |
aluminium ADC12 |
|
6 |
Globus Bearings |
● Standard Type 〇 C&U 〇 TPI(Taiwan) |
|
7 |
Motor Shaft |
●SUS410(2CR13) 〇 Welding Shaft: Diver 304 (Pump Side) + Carbon Ferro (Latus motoris) |
|
8 |
Terminatio Box |
Plastic ABS |
|
9 |
Terminatio Tabula |
Flamma retardans PBT |
|
10 |
Capacitor |
●CBB60 Testa plastica Capacitor 〇 CBB65 Explosio-probatio Capacitor 〇 450VL@220-240V Motor 〇 300VL@110-127VMotor |
|
11 |
Motor habitationi |
aluminium ADC12 |
|
12 |
Fan |
●Plastic PP 〇 Nylon PA6 |
|
13 |
Fan Cover |
Plastic PP |
|
14 |
Plug Funiculus |
● 3 Core Testimentum Cable 〇 Cables Plug |
|
15 |
Motor |
● Vexillum Filum Cupri 〇 Motorem Oconomicum Motor 3-Phase Motor 〇 60 HZ Motorisatum |
|
Exemplar |
DN1 |
DN2 |
Main Intallation Dimension (mm) |
||||||||||
|
a |
f |
h |
h1 |
i |
l |
m |
n |
n1 |
w |
s |
|||
|
PN59 |
G1 |
G1 |
42 |
250 |
151 |
63 |
10 |
149 |
89 |
117 |
94 |
51 |
10 |
|
PN60 |
G1 |
G1 |
42 |
250 |
151 |
63 |
10 |
149 |
89 |
117 |
94 |
51 |
10 |
|
PN65 |
G1 |
G1 |
44 |
279 |
178 |
76 |
13 |
165 |
96 |
140 |
114 |
59 |
10 |
|
PN70 |
G1 |
G1 |
45 |
279 |
178 |
76 |
13 |
167 |
96 |
140 |
114 |
58 |
10 |
|
Item |
1~220V/50Hz |
3~ 380V/50Hz |
|
PN59 |
2.1A |
0.7A |
|
PN60 |
2.7A |
0.8A |
|
PN65 |
4A |
1.5A |
|
PN70 |
5.8A |
2A |
|
Exemplar |
N.W. |
PCS/CTN |
G.W/CTN |
MEAS CM) |
PCS/CTN |
G.W/CTN |
MEAS CM) |
|
PN59 |
5.15 |
1 |
5.35 |
26X16X17.5 |
4 |
22.25 |
33.6X27.2X38.3 |
|
PN60 |
5.65 |
1 |
5.90 |
26X16X17.5 |
4 |
25.15 |
33.6X27.2X38.3 |
|
PN65 |
8.10 |
1 |
8.60 |
30.5X18X26 |
/ |
/ |
/ |
|
PN70 |
9.50 |
1 |
10.05 |
30.5X18X26 |
/ |
/ |
/ |
